| Series |  |  |  |  |  |  |  |  |  |  |  |  |  |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Operating Temperature | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -55℃~+125℃ | -65℃～+125℃ |
| Vibration | 10Hz～2000Hz 196m/s2 | 10Hz～2000Hz 196m/s² | 10Hz～2000Hz 196m/s² | 10Hz～2000Hz 196m/s2 | 10Hz～2000Hz 196m/s2 | 10Hz～2000Hz 196m/s² | 10Hz～2000Hz 196m/s² | 10Hz～2000Hz 196m/s2 | 10Hz～2000Hz 196m/s² | 50Hz～2000Hz 150m/s2 | 50Hz～2000Hz 147m/s2 | 10Hz～2000Hz 196m/s2 | 10 Hz to 2000 Hz, 147 m/s², transient interruption ≤ 1 μs |
| Random Vibration | Power Spectral Density: 0.4 G²/HzTotal Acceleration Root Mean Square (RMS): 23.1 G | Power Spectral Density: 0.4 G²/HzTotal Acceleration Root Mean Square (RMS): 23.1 G | Power Spectral Density: 0.4 G²/HzTotal Acceleration Root Mean Square (RMS): 23.1 G | Power Spectral Density: 0.4 G²/HzTotal Acceleration Root Mean Square (RMS): 23.1 G | Power Spectral Density: 0.4 G²/HzTotal Acceleration Root Mean Square (RMS): 23.1 G | Power Spectral Density: 0.4 G²/Hz Total Acceleration Root Mean Square (RMS): 23.1 G | - | Power Spectral Density: 0.4 G²/HzTotal Acceleration Root Mean Square (RMS): 28.4 G" | Power Spectral Density (PSD): 0.4 G²/Hz; Total Acceleration RMS Value: 23.1 G. | - | - | - | - |
| Shock | 980m/s2 6ms | 735m/s² 11ms | 735m/s² 11ms | 735m/s2 11ms | 735m/s² 11ms | 735m/s2 11ms | 735m/s² | 1200m/s2 6ms | 735m/s² 11ms | 1000m/s2 10ms | 735m/s2 11ms | 735m/s2 11ms | 980 m/s², transient interruption ≤ 1 μs |
| Rated Current | 1A | 3A | 3A | 3A | 3A | 3A | 3A | 5A | 3A | 3A | 3A | 3A | 1A（ 0.6） |
| Contact Resistance | ≤ 21mΩ | ≤ 10mΩ | ≤ 10mΩ | ≤ 10mΩ | ≤ 10mΩ | ≤ 10mΩ | ≤ 20mΩ | ≤ 10mΩ | ≤ 10mΩ | ≤ 10mΩ | ≤ 10mΩ | ≤ 10mΩ | ≤12.5mΩ |
| Insulation Resistance | ≥ 5000MΩ 100VDC | ≥ 5000MΩ | ≥ 5000MΩ | ≥ 5000MΩ | ≥ 5000MΩ | ≥ 5000MΩ 500VDC | ≥ 5000MΩ (500VDC)；≥ 100MΩ under damp heat conditions | ≥ 5000MΩ | ≥ 5000MΩ | ≥ 5000MΩ | ≥ 5000MΩ | ≥ 5000MΩ 500VDC | 5000 MΩ (normal condition), 100 MΩ (humid heat condition) |
| Dielectric Voltage | 250V | 800V | 800V | 800V | 800V | 600V | 800V (ambient temperature) | 1500V DC | 800V | 1000V | 600V | 800V | - |
| Mechanical Life | 200 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles | 500 cycles |
